Description
HIGHLIGHTS
High Precision Turret for the highest accuracy with 5,000 rpm, 5,4 kW and 18 Nm
- <10 μm tolerance in diameter
- <10 μm thermal stability by active cooling
- Highest dynamic due to optional linear drive in the X-axis
Complete machining by optional counter spindle and star turret
- Counter spindle with up to 6,000 rpm, 16 kW and 62 Nm
- VDI 30 star revolver with 5,000 rpm, 5,4 kW and 18 Nm
- DirectDrive drive with 12,000 rpm for highest surface accuracy
Machining of workpieces up to Ø 240 mm turning diameter and 500 mm turning length
- Circular diameter up to 510 mm
- Bar machining of workpieces up to Ø 66 mm
Accuracy
- Maximum stability and long-term accuracy
- Maximum thermal stability thanks to water-cooled, integrated spindle motors
- Unrivalled long-term precision with linear scales in the X-axis as standard
CONTROL & SOFTWARE
CELOS
Integrated digitization of the DMG MORI machines & the shop floor:
- CELOS Machine: APP-based user interface with access to all production-related information
- CELOS Manufacturing: 27 CELOS APPs for the optimal preparation & processing of orders
- Digital Factory: Continuous digital workflows from planning to production & service
