Description
Product Features
- Hydraulically moving carriage of forged steel with double slides, suitably hardened, ground and protected by dust scrapers.
- Moving beam sided on the table in rigid way.
- Easy adjustable stroke distance from front side.
- Working with foot pedal or two hand control.
- Roomy side tool holder shelves beside the machine.
- Die holder pins made in alloy steel with rapid conical change, hardened and ground to obtain a strong lock.
Technical Details
Workbench dimensions (mm) | 620×1050 |
Mobile punch operating speed (m/min.) | 470 |
Min.Max. Mobile and fixed pins height (mm) | 120/370 |
Max. stroke of mobile punch (mm) | 250 |
Advance and return speed(m/min.) | 1750/2000 |
Mobile and fixed pins height (mm) | 120 |
Mobile and fixed pins diameters (mm) | 55/63 |
Max. operating pressure in hydraulic circuit | 250 |
Max. operating pressure (ton) | 40 |
Height of workbench from the ground(mm) | 930 |
Engine Power (kW) | 4 |
Noise level(db) | 70 |
Hydraulic oil tank capacity (lt) | 70 |
Machine Width (mm) | 1150 |
Machine Length (mm) | 700 |
Machine Height (mm) | 950 |
Machine Weight (kg) | 920 |
