Description
Product Features
-
X axis control with servo motor
-
Ability to make more than one bend
-
CNC Control
-
7″ touch PC Panel.Turkish and English language opti
Technical Details
| Max Pipe Diameter (Ø) | 38 |
| Max Pipe Thickness (mm) | 3 |
| Max. Bending Radius (mm) | 220 |
| Bending Degree (°) | 0-90 |
| Shaft Diameter (mm) | 40 |
| Tightening Opening Distance (mm) | 50 |
| Pressure On Distance (mm) | 50 |
| Max.Bending Angle (°) | 95 |
| Min.-Max. Bending Distance (mm) | 250-5500 |
| Working Height (mm) | 1220 |
| Oil Tank Capacity (lt) | 160 |
| Engine Power (kW) | 7.5 |
| Machine Width (mm) | 1700 |
| Machine Length (mm) | 5200 |
| Machine Height (mm) | 1700 |
| Machine Weight (kg) | 2000 |
