Description
Standard Equipment
- CE Mark
- 3 Jaw Chuck 7” – SC Type
- 8” 4 Jaw chuck
- Quick change Tool Post
- Toolpost Guard
- Steady Rest
- Follow Rest
- Full Length Splash Guard-
- Halogen Work Light
- Coolant System
- Chuck Guard
- Sliding Toolpost Safety (Large Guard)
- Protective cover on leadscrew
- Dead Centre MT 3 x 2
- Spindle Centre Sleeve MT.5 x MT3
- Level Pads x 6 pcs
- Tool Set & Box
- Operation Manual & Parts List
Height of Centres: 171 mm
Swing over bed: Ø340 mm
Swing in Gap: 512 mm
Swing over cross slide: Ø210 mm
Distance between centres: 1000 mm
Width of bed: 230 mm
Gap width in front of faceplate: 150 mm
Spindle nose, internal taper: D1-4, MT No. 5
Spindle bore: Ø40 mm
Motor: 3 HP
Spindle speeds (8): 80 – 2000 R.P.M.
Quill travel: 112 mm
Tailstock morse taper: 3 MT
Dimensions: L2270 x W965 x H1745 mm
Weight: 850 kg
Electrics: 3/380/50 Hz
